#include <usrp2_sink_base.h>
Public Member Functions | |
| ~usrp2_sink_base () | |
| bool | set_antenna (int ant) |
| Set antenna. | |
| bool | set_gain (double gain) |
| Set transmitter gain. | |
| bool | set_lo_offset (double frequency) |
| Set transmitter LO offset frequency. | |
| bool | set_center_freq (double frequency, usrp2::tune_result *tr) |
| Set transmitter center frequency. | |
| bool | set_interp (int interp_factor) |
| Set transmit interpolation rate. | |
| void | default_scale_iq (int interpolation_factor, int *scale_i, int *scale_q) |
| Calculate default scale_iq for given interpolation factor. | |
| bool | set_scale_iq (int scale_i, int scale_q) |
| Set transmit IQ scale factors. | |
| int | interp () |
| Get transmit interpolation rate. | |
| bool | dac_rate (long *rate) |
| Get DAC sample rate in Hz. | |
| double | gain_min () |
| Returns minimum Tx gain. | |
| double | gain_max () |
| Returns maximum Tx gain. | |
| double | gain_db_per_step () |
| Returns Tx gain db_per_step. | |
| double | freq_min () |
| Returns minimum Tx center frequency. | |
| double | freq_max () |
| Returns maximum Tx center frequency. | |
| bool | daughterboard_id (int *dbid) |
| Get Tx daughterboard ID. | |
| bool | set_gpio_ddr (uint16_t value, uint16_t mask) |
| Set daughterboard GPIO data direction register. | |
| bool | set_gpio_sels (std::string sels) |
| Set daughterboard GPIO output selection register. | |
| bool | write_gpio (uint16_t value, uint16_t mask) |
| Set daughterboard GPIO pin values. | |
| bool | read_gpio (uint16_t *value) |
| Read daughterboard GPIO pin values. | |
| bool | start_streaming_at (usrp2::fpga_timestamp time) |
| First samples begin streaming to USRP2 at given time. | |
Protected Member Functions | |
| usrp2_sink_base (const char *name, gr_io_signature_sptr input_signature, const std::string &ifc, const std::string &mac) throw (std::runtime_error) | |
Protected Attributes | |
| bool | d_should_wait |
| usrp2::fpga_timestamp | d_tx_time |
Detailed Description
Base class for all USRP2 transmit blocks
Constructor & Destructor Documentation
| usrp2_sink_base::usrp2_sink_base | ( | const char * | name, |
| gr_io_signature_sptr | input_signature, | ||
| const std::string & | ifc, | ||
| const std::string & | mac | ||
| ) | throw (std::runtime_error) [protected] |
| usrp2_sink_base::~usrp2_sink_base | ( | ) |
Member Function Documentation
| bool usrp2_sink_base::dac_rate | ( | long * | rate | ) |
Get DAC sample rate in Hz.
| bool usrp2_sink_base::daughterboard_id | ( | int * | dbid | ) |
Get Tx daughterboard ID.
- Parameters:
-
[out] dbid returns the daughterboard id.
daughterboard id >= 0 if successful, -1 if no daugherboard installed, -2 if invalid EEPROM on daughterboard.
| void usrp2_sink_base::default_scale_iq | ( | int | interpolation_factor, |
| int * | scale_i, | ||
| int * | scale_q | ||
| ) |
Calculate default scale_iq for given interpolation factor.
| double usrp2_sink_base::freq_max | ( | ) |
Returns maximum Tx center frequency.
| double usrp2_sink_base::freq_min | ( | ) |
Returns minimum Tx center frequency.
| double usrp2_sink_base::gain_db_per_step | ( | ) |
Returns Tx gain db_per_step.
| double usrp2_sink_base::gain_max | ( | ) |
Returns maximum Tx gain.
| double usrp2_sink_base::gain_min | ( | ) |
Returns minimum Tx gain.
| int usrp2_sink_base::interp | ( | ) |
Get transmit interpolation rate.
| bool usrp2_sink_base::read_gpio | ( | uint16_t * | value | ) |
Read daughterboard GPIO pin values.
| bool usrp2_sink_base::set_antenna | ( | int | ant | ) |
Set antenna.
| bool usrp2_sink_base::set_center_freq | ( | double | frequency, |
| usrp2::tune_result * | tr | ||
| ) |
Set transmitter center frequency.
| bool usrp2_sink_base::set_gain | ( | double | gain | ) |
Set transmitter gain.
| bool usrp2_sink_base::set_gpio_ddr | ( | uint16_t | value, |
| uint16_t | mask | ||
| ) |
Set daughterboard GPIO data direction register.
| bool usrp2_sink_base::set_gpio_sels | ( | std::string | sels | ) |
Set daughterboard GPIO output selection register.
| bool usrp2_sink_base::set_interp | ( | int | interp_factor | ) |
Set transmit interpolation rate.
| bool usrp2_sink_base::set_lo_offset | ( | double | frequency | ) |
Set transmitter LO offset frequency.
| bool usrp2_sink_base::set_scale_iq | ( | int | scale_i, |
| int | scale_q | ||
| ) |
Set transmit IQ scale factors.
| bool usrp2_sink_base::start_streaming_at | ( | usrp2::fpga_timestamp | time | ) |
First samples begin streaming to USRP2 at given time.
| bool usrp2_sink_base::write_gpio | ( | uint16_t | value, |
| uint16_t | mask | ||
| ) |
Set daughterboard GPIO pin values.
Member Data Documentation
bool usrp2_sink_base::d_should_wait [protected] |
usrp2::fpga_timestamp usrp2_sink_base::d_tx_time [protected] |
